1-1Storage Temperature Range-30℃～80℃1-2Operating Temperature Range-20℃～80℃ 2.Standard Test Environment No.Item Specification2-1Temperature range25℃ ±5℃2-2Humidity range65%±10%3. Mechanical SpecificationNo.Item Specification3-1A：78mm B：43mm C：65.5mm 3-2Weight485g3-3Gear typeSteel Gear（Gear Ratio 232:1）3-6Limit angle No Limiter3-7Bearing2 Ball bearings3-8Horn gear spline One character (OD10mm)3-9Horn type steel3-10CaseAluminium（7075）3-11 Connector wire 300mm ±5 mm3-12MotorBrushless motor3-13Splash water resistanceNO4. Electrical Specification (Function of the Performance)No."Operating Voltage Range"24V4-1*Idle current(at stopped)40mA 4-2*No load speed0.2sec/60degree 50RPM 4-3*Runnig current(at no load)200 mA 4-4Peak stall torque120kg.cm1669.4oz.in4-5Stall current4000 mA4-6Rated Load32kg.cm≤4-7Rated current1000mm≤4-8KM 30kg.cm/A4-9Terminal resistance2.8ΩNo.Item Specification5-1Command signal Bus Packet Communication RS4855-2Protocol TypeHalf duplex Asynchronous Serial Communication5-3ID range 0-2535-4Communication Speed38400bps ~ 1 Mbps 5-5Running degree 360°(when 0～4096)5-6FeedbackLoad, Position,Speed, Input Voltage，Current,Temperature 5-7Position Sensor (Resolution)""Potentiometer (360°/4096 )"
